Z20K144MS系列

基于ARM CORTEX M4F的中高端微控制器，主频高达120 MHz，高达512K P FLASH + 128K D FLASH，4路CANFD，6路UART/LIN接口，满足ASIL-B，适用于车身控制、空调控制、照明控制、电子换挡器、安全带预紧、新能源类的各种应用。

zhixin-product

主要特点

  • 基于ARM CORTEX M4F的中高端微控制器
  • 主频高达120 MHz
  • 提供两块物理独立的大容量FLASH（512KB PFLASH + 128KB Data FLASH）
  • 4路CANFD
  • 6路UART/LIN接口
  • 满足ASIL-B
zhixin-product

目标应用

  • 适用于车身控制
  • 空调控制
  • 照明控制
  • 电子换挡器
  • 安全带预紧
  • 新能源类的各种应用
zhixin-product

开发工具

  • 开发环境
    • IAR Embedded Workbench for Arm | IAR Systems
    • Keil Embedded Development Tools for Arm, Cortex-M
    • GreenHills
  • 调试器
    • JLINK
    • Lauterbach
  • 烧写器
    • P&E Cyclone Pro
    • 戎象
    • 力捷丰

Software Version Reference

Software Name Version
Z20K144MS_SDK_Release_RTM_V1.0.1 1.0.1
Z20K144MS_SDK_Example_Release_RTM_V1.0.1 1.0.1
FreeRTOS 1.0.0
Bootloader 0.1
ZXPinsConfigurationTool 1.7.4
CodeAutoGeneratorTool 1.2.1
ZXCANBitRateCalculationTool 1.2
Safetylib Beta_0.6.0

Technical Documents Version Reference

Document Version
Z20K144MS_Series_Reference_Manual_RTM_V1.4 1.4
Z20K144MS_142MS_Datasheet_v1.0 1.0
Z20K144MS_ES_V1.2 1.2
Z20K144MS Series Safety Manual-v1.2 1.2
FMEDA_of_Z20K144MS_Series_v1.2 1.2

TECHNICAL DOCUMENTS QUICK REFERNCE

Document Description
Application Notes Specification of how to use a component in an application or process
Data Sheet Specification of the performance and other characteristics of a component
Release Notes Description of changes and issues in an upcoming update
Package Information Package details of the component
Reference Manual Specification of how to use a component in an application process
Product Brief Essential information to evaluate a product for design suitability quickly
User Guide Procedural manual with step-by-step instructions on how to perform a set of tasks
Supporting Manual A manual or a user guide of a supporting development tool.
